| Code | Q436 |
|---|---|
| Model | 38-436 |
| Capacity | 80kg Holding Power |
| Weight (kg) | 2.4 |
| Weight (m3) | 0.004 |
| Weight (Freight) | 2.4 |
| Dimensions (cm) | 29 x 19 x 7.5 |
38-436 Magnetic Base - One Lock (Large) 80kg Holding Power
Features
- Accepts all MX Dial Indicators
- V-Base for placing on round surfaces
- On/Off lever releases magnet
- No risk of marking polished surfaces
- Mounts test indicators with 1/4" spigot
- On/Off switch conveniently located
- Mechanical one lock clamping
Specifications
- Compare 7 Products
- ORDER CODE
- MODEL
- Base Sizemm
- Holding Powerkg
- Main Rodmm
- Sub Rodmm
- Reachmm
- Nett Weightkg
- Q436
- Heavy Duty
One Lock - 60 x 50 x 55
- 80
- Ø18 x 150
- Ø14 x 140
- 330
- 1.7
- M055
- Dial & Mag Base Kit
- ~
- ~
- ~
- ~
- ~
- 2.26
- M050
- Standard
Dual Lock Type - 64 x 50
- 60
- 180
- 150
- ~
- 1.66
- M051
- Deluxe - One Lock
- 62 x 50
- 60
- ~
- ~
- 320
- 1.68
- Q435
- Standard with
Fine Adjuster - 59 x 50 x 55
- 80
- Ø12 x 173
- Ø10 x 162
- 300
- 1.5
- Q4351
- Heavy Duty with
Fine Adjuster - 59 x 50 x 55
- 60
- Ø16 x 200
- Ø12 x 150
- 335
- 1.6
- Q430
- Small
One Lock - 36 x 29 x 35
- 30
- Ø20 x 70
- Ø20 x 65
- 130
- 0.58
| ORDER CODE | Heavy Duty One Lock |
|---|---|
| MODEL | 60 x 50 x 55 |
| Base Sizemm | 80 |
| Holding Powerkg | Ø18 x 150 |
| Main Rodmm | Ø14 x 140 |
| Sub Rodmm | 330 |
| Reachmm | 1.7 |
| Nett Weightkg |
