| Code | C3124A |
|---|---|
| Model | WS3.0CI |
| Capacity | 90 Litre Tank / 3hp |
| Weight (kg) | 60 |
| Weight (m3) | 0.382 |
| Weight (Freight) | 127.206 |
| Dimensions (cm) | 115 x 40 x 83 |
Air Compressor WS3.0CI 90 Litre Tank / 3hp
Description
Air Command 3HP 90L Workshop Air Compressor 230VFeatures
- Powerful 2.2kW 3.0HP Motor – 370 L/min (12.7 CFM) pump displacement for strong, consistent air delivery.
- High Output – 210 L/min FAD (7.4 CFM) @ 90psi for reliable performance.
- Big 90L Tank – Longer run time, fewer refills.
- Heavy-Duty Build – Cast iron 2-cylinder single stage pump for durability and long service life.
- Easy to Move – Robust wheels and rubber foot kit for portability and stability.
- Single Phase 230V 15A Power Supply Requirements
- Dimensions (LxWxH): 115 x 40 x 83cm
- Come with wheels
- 15A Plug
Specifications
- Compare 6 Products
- ORDER CODE
- MODEL
- Drive Type
- Piston DisplacementCFM / LPM
- Free Air DeliveryCFM / LPM
- CylindersType
- Max. PressurekPa
- Max. PressurePSI
- Air Receiver Tank SizeLitre
- Motor Speedrpm
- Motor PowerkW / hp
- Voltage / AmperageV / amp
- Nett Weightkg
- C3124A
- WS16
- V-Belt
- 12.7 / 370
- 7.4 / 210
- 2
- 1000
- 145
- 90
- 1440
- 2.2 / 3
- 230 / 15
- 106
- C3124
- AC16i
- V-Belt
- 14.9/ 421
- 11.9 / 337
- 2
- 1000
- 145
- 50
- 1440
- 2.2 / 3
- 240 /15
- 52
- C3118
- AC13
- V-Belt
- 13 / 365
- 7.4 / 212
- 2
- 862
- 125
- 50
- 1440
- 1.5 / 2
- 240 / 10
- 53
- C3122
- AC12i
- V-Belt
- 12 / 339
- 8.8 / 252
- 2
- 1000
- 145
- 50
- 1440
- 1.5 / 2
- 240 / 10
- 42
- C3120
- AC15
- V-Belt
- 12.4 / 350
- 9.3 / 262
- 2
- 862
- 125
- 50
- 1440
- 2.2 / 3
- 240 / 15
- 60
- C3126
- AC1600i
- V-Belt
- 14.9 / 421
- 11.9 / 337
- 2
- 1000
- 145
- 100
- 1440
- 2.2 / 3
- 240 / 15
- 60
| ORDER CODE | WS16 |
|---|---|
| MODEL | V-Belt |
| Drive Type | 12.7 / 370 |
| Piston DisplacementCFM / LPM | 7.4 / 210 |
| Free Air DeliveryCFM / LPM | 2 |
| CylindersType | 1000 |
| Max. PressurekPa | 145 |
| Max. PressurePSI | 90 |
| Air Receiver Tank SizeLitre | 1440 |
| Motor Speedrpm | 2.2 / 3 |
| Motor PowerkW / hp | 230 / 15 |
| Voltage / AmperageV / amp | 106 |
| Nett Weightkg |
