Shown with Optional Mandrel Adaptors N023 and Riveter Set N001

Shown with Optional Mandrel Adaptors N023 and Riveter Set N001

Code	N028
Capacity	Steel - Zinc Plated
Weight (kg)	0.88
Weight (m³)	0.001
Weight (Freight)	0.88
Dimensions (cm)	10 x 20 x 5

HAFCO

1 Year Warranty

Product Brochure

Rivet Stud Inserts - M8 x 1.25mm Steel - Zinc Plated

Description

Suits RNB40 Twin Handle Nut Riveter

Features

Steel - Zinc Coated
Fast & easy installation from one side
Adds a threaded stud to thin sheet metal
Knurled section of the body for anti-rotation
** Easy to install with the RNB40 Nut Riveter

** NOTE: Requires M8 Stud Rivet Mandrel, sold separately (Order Code: N023)

Includes

50 x Rivet Stud Insert - M8 x 1.25mm
20mm thread length

Specifications
