Code	T005B
Model	4MT
Capacity	M8 - M18
Weight (kg)	1.74
Weight (m³)	0.001
Weight (Freight)	1.74
Dimensions (cm)	19 x 6.5 x 6

TOOLMASTER

1 Year Warranty

Taiwan

Product Brochure

Tapping Chuck - Fixed 4MT M8 - M18

Description

Suits drilling machines with tapping/reverse cycles

Features

One piece solid design to reinforce chuck slipping
Positive clamping on the square section of the tap
Adjustable spring collet to suit all sizes in the range

Specifications

Compare 2 Products
ORDER CODE
Shank MountMT
Metric Tapping Rangemm
Metric Shank Diameter Rangemm
Imperial Tapping Rangeinch
Imperial Shank Diameter Rangeinch
Body Diametermm
Nett Weightkg

T005B
4MT
M8 - M18
7 - 14
5/16" - 3/4"
9/32" - 9/16"
Ø50
1.7

T004B
3MT
M8 - M18
7 - 14
5/16" - 3/4"
9/32" - 9/16"
Ø50
1.4

ORDER CODE	4MT
Shank MountMT	M8 - M18
Metric Tapping Rangemm	7 - 14
Metric Shank Diameter Rangemm	5/16" - 3/4"
Imperial Tapping Rangeinch	9/32" - 9/16"
Imperial Shank Diameter Rangeinch	Ø50
Body Diametermm	1.7
Nett Weightkg
