| Code | Q230 |
|---|---|
| Model | 34-230 |
| Capacity | 35-50mm |
| Weight (kg) | 1 |
| Weight (m3) | 0.002 |
| Weight (Freight) | 1 |
| Dimensions (cm) | 39 x 16 x 4 |
Dial Bore Gauge 34-230 35-50mm
Features
- Suitable for the inspection of deep internal diameters
- Moveable anvil on one side with interchangeable insert type anvils on the other side (above 35mm)
- Self aligning mechanism by centering plate
- Easy anvil replacement
- Dial face cover supplied
- Dial indicator stem 8mm
- For imperial reading or data output the Q2205 (34-2205) can be used instead of the dial indicator supplied
Specifications
- Compare 4 Products
- ORDER CODE
- Rangemm / inch
- Accuracymm
- Readable Depthmm / inch
- AnvilsNo.
- SpacersNo.
| ORDER CODE | 35 - 50mm |
|---|---|
| Rangemm / inch | 0.01mm |
| Accuracymm | 125mm |
| Readable Depthmm / inch | 4 |
| AnvilsNo. | 4 |
| SpacersNo. |
