| Code | A345F |
|---|---|
| Model | JGS0871 |
| Capacity | 18000kg Air Hydraulic Bottle Jack |
| Weight (kg) | 14 |
| Weight (m3) | 0.017 |
| Weight (Freight) | 14 |
| Dimensions (cm) | 39 x 20 x 22 |
Air Hydraulic Bottle Jack JGS0871 18000kg Air Hydraulic Bottle Jack
Features
- Heavy duty construction great for industrial and commercial applications
- Great for lifting farm vehicles, machinery, construction equipment
- A heavy-duty air motor provides maximum power, integrated bypass and overload valves
- Fully polished and chrome cylinder rams enhanced with high performance seals added durability and longer life
- Fast and efficientair pump reduces lifting time and has a built-in relief mechanism which prevents the jack from being used beyond its maximum allowable capacity
- Unique design allows for manual operation when air is not available
- Side carry handle
- Safety spring ram retention
- Screw extension for extra height
- Lifting range: 178mm to 328mm (with screw extension)
- Ram travel: 87mm, screw extension travel: 63mm
- Air pressure: 0.75 - 0.85mpa/108 – 123psi
- Complies with ASME safety standards
Specifications
- Compare 5 Products
- ORDER CODE
- Lift CapacityTonne
- Hydraulic Liftmm
- Insert Screw - Adjustable Heightmm
- Minimum Heightmm
- Maximum Heightmm
- Base Areamm
- Nett Weightkg
| ORDER CODE | 20 |
|---|---|
| Lift CapacityTonne | ~ |
| Hydraulic Liftmm | ~ |
| Insert Screw - Adjustable Heightmm | 178 |
| Minimum Heightmm | 328 |
| Maximum Heightmm | ~ |
| Base Areamm | ~ |
| Nett Weightkg |
